USB 3.1/2.0 Repeaters

Regular USB cables only allow user to connect from USB host to devices in few meters range. For example, a standard passive USB 3.0 cooper cable can normally only go up to 3 meters. As one major developer of USB extension solution, Newnex has developed numbers of extenders and hub products to break the length barrier for USB applications.

Newnex’s FireNEX™ series USB extenders and hubs are featured with the most advanced repeater technology. The fiber optic extender is capable of extending USB SuperSpeed signal up to 500 meters via a single fiber cable.

USB Optical Repeaters in Comparison
	FireNEX™-10G	FireNEX™-5000Plus	FireNEX™-5000H	FireNEX™-5000H+
USB 3.1 Max Data Rate	10Gbps	5Gbps	5Gbps	5Gbps
USB 2.0 Backward Compatibility	Yes	Yes	No	Compatible on Win OS
Max Extension Range	500m	200m	300m	300m
Downstream USB Port	2	4	2	2
Fiber Type	Single Mode	Single Mode	Multimode OM3	Multimode OM3 / Single-mode Optional
Fiber Hot Plug & Play	No	Yes	Yes	Yes

USB Fiber Repeaters

USB Fiber Repeaters

FireNEX™-5000H

USB 3.0 2-Port Fiber Repeater

FireNEX™-5000H+

2-Port USB 3.0/2.0/1.1 Optical Fiber Repeater

FireNEX™-10G

USB 3.1 Gen 2 10Gbps 2-Port Fiber Repeater

FireNEX™-5000Plus

USB 3.0/2.0 4-Port Fiber Repeater
