Key Features
- Extend USB-C connectivity 5Gbps data and power over CAT 6a/7 Ethernet cable up to 90m (300 ft.)
- Support USB 3.2 Gen 1 (USB 3.0) data rate up to 5Gbps
- USB 2.0/1.1 Backward Compatible
- Isochronous USB Support
- Deliver power over CAT cable to the USB-C device port with multiple USB PD profile, including 5V, 9V, 12V, 20V
- Bi-directional RS-232 serial pass through
- Durable Metal Enclosure
- USB-IF standard USB-C locking port
- Plug and Play for Windows, macOS, Linux, Chrome OS Support
In the Box
- 1x FireNEX-CAT6 Local Unit
- 1x FireNEX-CAT6 Remote Unit
- 1x 36V DC Power Adapter (US)
- 1x USB 3.2 A to C Cable, 1m
- 1x FireNEX-CAT6 Manual
Specifications
RANGE
Max. Extension
90m (300 ft.)
DATA RATE
USB 2.0/1.1
Backward Compatible
USB Transfer Type
Bulk / Isochronous / Control / Interrupt
LOCAL UNIT
Dimensions
77 x 45 x 21 mm
Enclosure Material
Anodized Aluminum
Upstream USB Port
1x USB-C to Host with Locking
Power Plug
2.1 x 5.5 x 10mm Center positive
Mated RS-232 Header
3-Pin Phoenix 1881338
REMOTE UNIT
Dimensions
77 x 45 x 21 mm
Enclosure Material
Anodized Aluminum
Downstream USB Port
1x USB-C to Device with Locking
USB Port Power Profile
5V/3A, 9V/3A, 12V/2A, 20V/1.5A
Power Source
Power over CAT Cable
Mated RS-232 Header
3-Pin Phoenix 1881338
COMPATIBLE CAT CABLE
Length
90m (300 ft.) Max.
Type
Shielded or Foiled Twisted Pair (S/FTP or F/FTP)
CAT 6a/7 cable
POWER SUPPLY
Power Input
100-240V AC, 50/60Hz
ENVIRONMENTAL
Operating Temperature
0 °C to 50 °C (14 °F to 185 °F)
Operating Humidity
20% to 80% relative humidity, non-condensing
COMPLIANCE AND COMPATIBLITY
Environmental
RoHS 2 & 3, REACH
SUPPORT
Warranty
1-year Manufacture Warranty
FAQ
Q: Does FireNEX™-CAT6 support DP Alt Mode?
A: No, FireNEX™-CAT6 only transfers USB 5Gbps data and power.
Q: How many USB hub tiers does FireNEX™-CAT6 consists of?
A: FireNEX™-CAT6 consists of one USB hub.
Q: Is FireNEX™-CAT6 backward compatible with USB 2.0/1.1 peripherals?
A: Yes, FireNEX™-CAT6 is backward compatible with USB 2.0/1.1 protocols.
Q: Does FireNEX™-CAT6 support isochronous USB data transfer?
A:Yes, FireNEX™-CAT6 supports isochronous USB data transfer.
Q: Do the USB-C ports on the FireNEX™-CAT6 support flippable plug-in?
A:Yes, both the upstream and downstream USB-C ports support flipped plug-in.
Q: Can I use an UTP CAT6a cable with FireNEX™-CAT6?
A: No. It’s recommended to use a shielded (S/FTP or F/FTP) CAT 6a or 7 cable with FireNEX-CAT6.
Installation Setup
